TS1800-ZDZXPlastic BottlesPacking machineFeatures of the product:

The design of special gripper is adopted to ensure that there is no drop in the packing process, which solves the difficulty of deviating the center of gravity of the special-shaped bottle

Servo control system, with European flexible motion trajectory design, to ensure accurate positioning, boxed movement without shaking

According to customer packing arrangement needs, the equipment automatically realizes the grouping arrangement

Plastic bottle pre-packing equipment on the upper mouth of the carton to automatically open positioning, to ensure smooth packing, no card box worry

Plastic bottle Box machine has a wide range of application, can meet a variety of specifications of product packing

Control mode: plc+ touch screen + standard control button + signal switch, divided into automatic/manual control mode

Fault points can be found via touch screen for easy troubleshooting

This machine is suitable for grease, daily, medicine, bottled food and other industries

Can be based on user requirements non-calibration to do

Technical parameters

Model: TS1800-ZD6

Applicable products: Cosmetic bottles, medicine bottles

Suitable for bottle type: Oval bottle, flat bottle, square bottle

Packing Speed: 60 cases/hour

Gripper Claw: 1 Groups

Mechanical Dimensions: (L) 1800 (W) 1600 (H) 2750mm

Packing Specifications: (L) (W) (H) 600mm

Packing Specifications: (L) (W) (H) 300mm

Using power: 380v,50hz

Use of gas Source: 5-6kg/cm2 460L/min

Mechanical Weight: 800kgs

Plastic bottle Box machine adopts a new type of composite structure, including box-forming device, whole column device, filling device and sealing device and other functional units, respectively, complete the corresponding functional action, each device is installed on the same host rack.

Plastic bottle Box machine has a wide range of applications, small footprint, reliable performance, easy to operate, can be widely used in chemical, pharmaceutical, salt, food and other industries of various products of fully automatic packing. Although the fuselage is compact and can be integrated into compact packaging machinery, it meets all your requirements in terms of arrival distance and payload. Equipped with motion control and tracking performance, plastic bottle box machine is very suitable for flexible packaging system, greatly shortening the packaging cycle time. Extremely high accuracy, coupled with superiorPlastic Bottle Conveyor BeltTrack performance, whether it's a fixed-position operation or a motion operation, with high pickup accuracy. Small size, fast speed, specifically based on packaging applications have been optimized. Equipped with a full set of auxiliary equipment (from integrated air and signal system to the gripper), can be used to support the use of packaging software, mechanical integration is simple, programming is very convenient.

Advantages of plastic bottle box machines:

1, automatic packaging assembly line, Plastic bottle box machine is the core of the whole system operation.

2, Plastic bottle box machine used to complete the transport packaging, it is the packaging of finished products in a certain arrangement into a carton of a machine.

3, the use of P.L.C + touch display control. With the lack of bottle alarm shutdown, no bottle of non-boxed safety device.

4, greatly facilitate the operation, management, reduce production personnel and labor intensity, is an indispensable equipment for the production of automated scale.

5, applicable to eachPlastic Bottle production LineAll kinds of bottle types on the small bottle mouth.
